HIGHLIGHTS
ADDITIONAL PHOTOS ON REQUEST
Highlights include a refurbished Volvo MD7A Diesel Engine with less than 100 hours, Chart Plotter, Radar, Auto Pilot, Custom Winter Cover, new bottom paint, 4 person Life Raft, Highfield Dinghy with aluminum bottom.
Magic Dragon has traveled the East Coast Atlantic Ocean from Maine to Delaware and much of the Chesapeake Bay. Her full length keel tracks well and, with only 4ft 2in draft, she can go most anywhere on the Chesapeake. Her rig can be balanced with Main Sail in-mast furling along with Genoa furling. With Main and Stay Sail Cutter Rig, tacking is accomplished by simply turning the wheel for easy single handling.
CAPE DORY 30C
Sailboat Specifications
Hull Type: Full Keel
Rigging Type: Cutter
LOA: 30.21 ft / 9.21 m
LWL: 22.83 ft / 6.96 m
S.A. (reported): 437.00 ft / 40.60 m
Beam: 9.00 ft / 2.74 m
Displacement: 10,000.00 lb / 4,536 kg
Ballast: 4,000.00 lb / 1,814 kg
Max Draft: 4.17 ft / 1.27 m
Construction: FG
Ballast Type: Lead
First Built: 1976
Last Built: 1987
# Built: 363
Builder: Cape Dory Yachts
Designer: Carl Alberg
Auxiliary Power/Tanks (orig. equip.)
Make: Volvo
Type: diesel
HP: 13
Fuel: 20 gals / 76 L
Accomodations
Water: 60 gals / 227 L
Sailboat Calculations
S.A. / Displ.: 15.11
Bal. / Displ.: 40.00
Disp: / Len: 375.18
Comfort Ratio: 33.06
Capsize Screening Formula: 1.67
S#: 1.15
Hull Speed: 6.40 kn
Pounds/Inch Immersion: 734.17 pounds/inch
Rig and Sail Particulars
I: 35.00 ft / 10.67 m
J: 13.25 ft / 4.04 m
P: 31.50 ft / 9.60 m
E: 13.00 ft / 3.96 m
S.A. Fore: 231.88 ft / 21.54 m
S.A. Main: 204.75 ft / 19.02 m
S.A. Total (100% Fore Main Triangles): 436.63 ft / 40.56 m
S.A./Displ. (calc.): 15.10
Est. Forestay Length: 37.42 ft / 11.41 m
Mast Height from DWL: 40.50 ft / 12.34 m
Sailboat Organizations
Designer: Carl Alberg
Builders: Cape Dory Yachts
Associations: Cape Dory Sailboat Owners Association
ADDITIONAL PHOTOS ON REQUEST
Highlights include a refurbished Volvo MD7A Diesel Engine with less than 100 hours, Chart Plotter, Radar, Auto Pilot, Custom Winter Cover, new bottom paint, 4 person Life Raft, Highfield Dinghy with aluminum bottom.
Magic Dragon has traveled the East Coast Atlantic Ocean from Maine to Delaware and much of the Chesapeake Bay. Her full length keel tracks well and, with only 4ft 2in draft, she can go most anywhere on the Chesapeake. Her rig can be balanced with Main Sail in-mast furling along with Genoa furling. With Main and Stay Sail Cutter Rig, tacking is accomplished by simply turning the wheel for easy single handling.
CAPE DORY 30C
Sailboat Specifications
Hull Type: Full Keel
Rigging Type: Cutter
LOA: 30.21 ft / 9.21 m
LWL: 22.83 ft / 6.96 m
S.A. (reported): 437.00 ft / 40.60 m
Beam: 9.00 ft / 2.74 m
Displacement: 10,000.00 lb / 4,536 kg
Ballast: 4,000.00 lb / 1,814 kg
Max Draft: 4.17 ft / 1.27 m
Construction: FG
Ballast Type: Lead
First Built: 1976
Last Built: 1987
# Built: 363
Builder: Cape Dory Yachts
Designer: Carl Alberg
Auxiliary Power/Tanks (orig. equip.)
Make: Volvo
Type: diesel
HP: 13
Fuel: 20 gals / 76 L
Accomodations
Water: 60 gals / 227 L
Sailboat Calculations
S.A. / Displ.: 15.11
Bal. / Displ.: 40.00
Disp: / Len: 375.18
Comfort Ratio: 33.06
Capsize Screening Formula: 1.67
S#: 1.15
Hull Speed: 6.40 kn
Pounds/Inch Immersion: 734.17 pounds/inch
Rig and Sail Particulars
I: 35.00 ft / 10.67 m
J: 13.25 ft / 4.04 m
P: 31.50 ft / 9.60 m
E: 13.00 ft / 3.96 m
S.A. Fore: 231.88 ft / 21.54 m
S.A. Main: 204.75 ft / 19.02 m
S.A. Total (100% Fore Main Triangles): 436.63 ft / 40.56 m
S.A./Displ. (calc.): 15.10
Est. Forestay Length: 37.42 ft / 11.41 m
Mast Height from DWL: 40.50 ft / 12.34 m
Sailboat Organizations
Designer: Carl Alberg
Builders: Cape Dory Yachts
Associations: Cape Dory Sailboat Owners Association
- Year
- 1982
- Condition
- Used
- Make
- Cape Dory
- Model
- 30
- Price
- $29,500
- City
- Georgetown
- State
- Maryland - MD
- Zip Code
- 21930
